Surface Mounted Multi Roll Toilet Tissue Dispenser

B-3588 Category: Brand:

Series: Trimline
Cabinet: 18-8, type-304, heavy-gauge stainless steel.
Finish: Satin finish Stainless Steel
Spindle: 18-8, Type-304, 18-gauge (1.2mm), 1″ diameter (25mm) stainless steel tubing with plastic end caps. Theft resistant. Removable with
key provided. Holds two rolls up to 5-1/8″ (130mm) diameter (1500 sheets)
Door: 18-8, Type-304, 20-gauge (0.9mm) stainless steel with satin-finish. Secured to cabinet with two rivets. Equipped with a tumbler lock.
Unit Dimension: 345 (W) x 215 (H) x 115 (D) mm.

B-3588 Category: Brand:
  • Technial Data: https://www.samrick.in/wp-content/uploads/2018/10/B-3588__B-3588_td.pdf
  • Bim Object: https://www.samrick.in/wp-content/uploads/2018/10/B-3588__BIM-Toilet_Tissue_Dispenser-Bobrick-TrimLineSeries-B-3588.rfa
  • Care and Maintenance: https://www.samrick.in/wp-content/uploads/2018/10/B-3588__Bulletin-TB-21_Cleaning_and_Maintenance_of_Stainless_steel.pdf
  • Cad: https://www.samrick.in/wp-content/uploads/2018/10/B-3588__CAD-B-3588.dxf
  • E catalog: https://www.samrick.in/wp-content/uploads/2018/10/B-3588__E-Catalogue_BobrickInternational.pdf
